08D3 Compact – compact checkweigher for small and medium formats
The 08D3 Compact is an extremely versatile and functional in-line checkweighing system , specially developed for small and medium-sized packaging.
With a maximum capacity of 1,600 g , an accuracy of ± 0.5 g and a production speed of up to 300 ppm , this checkweigher is the ideal instrument for the most common weight control needs in the pharmaceutical, food and cosmetics industries.
It is applicable to a wide range of packaging: trays, bags, cans, bottles and boxes of various shapes and dimensions .
Key features
- Weighing capacity: up to 1600g
- Accuracy: from ± 0.5 g
- Production speed: up to 300 pieces per minute (ppm)
- Construction: completely made of stainless steel
- Protection level: IP54 (higher protection versions available)
- Weighing system: dual load cell for greater stability and precision
- High level of configurability with available options
Advantages for production
- Versatility – suitable for different types of packaging (boxes, trays, bottles, cans, bags)
- Reliability – constant precision and repeatability even at higher speeds
- Resistance and durability – stainless steel housing and IP54 protection
- Flexibility – ability to adapt with a wide range of options (rejection systems, additional interfaces, protective tunnels, integration with ERP systems)
- Easy maintenance – modular construction and quick-dismount conveyor belts
