MFN11 – metal detector for conveyor belts
The MFN11 is a reliable in-line metal detector designed for the inspection of loose and packaged products on conveyor belts. Thanks to multi-frequency technology, it achieves high sensitivity in detecting ferrous, stainless steel and non-ferrous metal contaminants, even in packaging with challenging properties.
Made entirely of stainless steel, with an IP65 protection level, this model is resistant, easy to clean and fully adaptable to different types of lines.
Technical characteristics
| Specification | Value |
|---|---|
| Weighing range | up to 10,000 g |
| Linear speed | up to 65 m/min |
| Pneumatic supply | 0.6 MPa |
| Air consumption (for rejection) | 1 Nl |
| Power supply | 230 V, 50/60 Hz, single-phase |
| Power consumption | 650 W |
| Metal parts finish | Stainless steel, IP54–IP65 |
| Operating environment | from +5 °C to +40 °C, no condensation (indoor) |
| Regulations | Compliance with CE regulations and international standards for electrical safety and electromagnetic compatibility |
Key features
- High sensitivity and reliability when operating with conveyor belts
- Flexibility for different product formats (bags, boxes, trays, packages)
- Robust stainless steel construction with IP65 protection
- Multiple rejection options (air-jet, piston systems, flaps)
- Easy operation through intuitive electronics
Advantages
- Prevents the entry of metal contaminants into the production process
- Easy integration with existing lines
- Certified and compliant with HACCP, GMP, and ISO standards
