Devices for counting and checking labels

Wide Range label counting and verification devices enable label control and counting during the transfer process between roll systems. They combine the functions of counting, label presence verification and winding/unwinding in a single module.

RW Devices for counting and checking labels

Technical characteristics – RW Counter Check series

Parameter

Basic / Plus

BIG version

Max. label width

up to 150 mm

up to 230 mm

Speed

~50 m/min

~50 m/min

Max. roll diameter

up to 300 mm

up to 400 mm

Mandrel (core) diameter

40–110 mm

76 mm (fixed or expansion)

Force

150 watts

400 watts

Dimensions (W×D×H)

844 × 385 × 374 mm

1,215 × 560 × 500 mm

Weight

~30 kg

~45 kg

Features and benefits

  • Label counting with automatic stop when a preset number is reached
  • Label presence check and gap detection; ultrasonic sensor can be used for transparent labels
  • Self-learning algorithm for automatic label length recognition
  • The possibility of working as a winder/unwinder with additional options
  • Compatibility with systems for printing and further processing of labels
