Label winders
Wide Range label removers enable precise handling of label rolls before or after labeling/printing. Powerful motors and stable construction allow working with large rolls and ensure continuous work without paper tearing.
RWR / UWR Series
Technical characteristics – RWR / UWR series
|
Parameter |
RWR/UWR-S (Standard) |
RWR/UWR-L (Large) |
RWR/UWR-BIG |
|
Max. label width |
up to 130 mm |
up to 230 mm |
up to 230 mm |
|
Winding/unwinding speed |
up to 25 m/min |
up to 25 m/min |
up to 40 m/min |
|
Max. roll diameter |
300 mm |
300 mm |
400 mm |
|
Mandrel (core) diameter |
40–110 mm |
40–110 mm |
76 mm (fixed or expansion) |
|
Power / consumption |
30 watts |
30 watts |
150 watts |
|
Dimensions (W×D×H) |
335 × 470 × 365 mm |
on |
559 × 495 × 478 mm |
|
Weight |
~12 kg |
on |
~21 kg |
Features and benefits
- Possibility of winding / unwinding in both directions (clockwise / anticlockwise)
- Automatic material tension monitoring and adjustment (tension control)
- Compatibility with numerous printers and integration systems
- Robust construction, stability when working with large rolls
- Options for precise stopping, roll end signaling, paper protection
