Paper feeding devices
Wide Range paper feeders enable precise feeding of sheets, cards, coupons or envelopes in production or labeling processes. They are ideal for applications where it is necessary to continuously and reliably insert paper or cardboard into the line.
WR FEEDER (250 / 400 / 500 versions)
Technical characteristics – WR Feeder 250 / 400 / 500
|
Parameter |
WR Feeder 250 |
WR Feeder 400 |
WR Feeder 500 |
|
Product width |
60 – 250 mm |
up to 400 mm |
up to 500 mm |
|
Product length |
60 – 300 mm |
60 – 300 mm |
60 – 300 mm |
|
Product thickness |
0.2 – 10 mm |
0.2 – 10 mm |
0.2 – 10 mm |
|
Retraction speed |
up to 70 m/min |
up to 50 m/min |
up to 40 m/min |
|
Engine |
Stepper motor |
Stepper motor |
Stepper motor |
|
Power supply |
230V AC, 50Hz |
230V AC, 50Hz |
230V AC, 50Hz |
|
Dimensions (W×D×H) |
840 × 250 × 490 mm (height) |
840 × 400 × 490 mm (height) |
840 × 500 × 490 mm (height) |
|
Weight |
~35 kg |
~40 kg |
~45 kg |
Features and benefits
- Adjustable rubber rollers for precise gripping and feeding of various materials
- Micro-adjustment of side rollers for format flexibility
- Minimum quantity sensor in the hopper for automatic stop in case of lack of material
- Possibility of integrating inkjet markers for printing variable data such as barcodes, dates and text
- Different versions (L, XL) for working with longer products or multiple print/label heads
